Sivga Audio SV021 Robin Default - REW Loop Measurement's report - Reference Audio Analyzer

Reports / Sivga Audio / SV021 Robin / Default - REW Loop - report for a pro

Sivga Audio SV021 Robin: Default - REW Loop (report for a pro)

After testing in the benchmark mode in the Reference Audio Analyzer software, the data is added to the online database of the RAA website.

You can view the test results on the comparison pages and summary reports for beginners and professionals. You can go to the desired report or comparison/selection service through the menu on this page. Additionally, you can go to the comparison pages from any graph in this report and add other tested products for direct comparison.



This is a summary report of headphones for professionals.

You can additionally look for Sivga Audio SV021 Robin Default - REW Loop






Sensitivity average in band from 100 Hz - 10 kHz-27.3dB/V SPL
-41.7dB/mW SPL
Impedance average in band from 40 Hz - 15 kHz36.6ohm
For 90 dB SPL, a voltage is required117.3dBV
734759.145VRMS
Taking into account the peak factor of 9 dB for the music signal126.3 dBV
2070832.632VRMS
Measurements were performed on the stand:Human: romanrex


Frequency response Sivga Audio SV021 Robin Default - REW Loop headphone

АЧХ - Стенд: Human: romanrex

Your browser does not support Canvas
Graphics setting view
Channel

Range

Frequency band

Smoothing


Brief information

Clicking on the graph will take you to the comparison page of different models with advanced graph display settings.



Impedance / Electric phase Sivga Audio SV021 Robin Default - REW Loop headphone

Your browser does not support Canvas
Graphics setting view
Channel

Frequency band


Channel:LeftRight
Impedance average in band from 40 Hz - 15 kHz36.4 36.8ohm
Resistance at 1 kHz35.8 36.6ohm
Resistance at 500 Hz35.2 35.8ohm
The minimum value in band from 40 Hz - 15 kHz34.5 35.1ohm
The maximum value in band from 40 Hz - 15 kHz38.9 39.2ohm


Your browser does not support Canvas
Graphics setting view
Channel

Range

Frequency band


Channel:LeftRight
Phase deviation is the average in the range 40 Hz - 15 kHz0.9 1.0°
Phase at 1 kHz1.7 1.6°
Phase at 500 Hz-0.2 -0.0°
The minimum value in band from 40 Hz - 15 kHz-3.4 -2.3°
The maximum value in band from 40 Hz - 15 kHz9.7 9.8°



Brief information

Clicking on the graph will take you to the comparison page of different models with advanced graph display settings.



Frequency response and sensitivity Sivga Audio SV021 Robin Default - REW Loop headphone

Your browser does not support Canvas
Graphics setting view
Channel

Frequency band

Smoothing


Channel:LeftRight
Sensitivity average in band from 100 Hz - 10 kHz-27.5 -27.2dB/V SPL
Sensitivity average in band from 100 Hz - 10 kHz-41.9-41.5 dB/mW SPL
Sensitivity at 1 kHz-28.4-28.4dB/V SPL
Sensitivity at 500 Hz-34.3-35.1dB/V SPL


Your browser does not support Canvas
Graphics setting view
Type of chart

SPL


SPLVoltageCurrentPower
dB SPLdBVVRMSdB(mA)mAdBmmW
6087.32323511663521110214759203492
7097.3734761262008713112147592034924
8010723235113663521091221475920349239
901177347591462008713113214759203492395
100127232351215663521087142147592034923947
11013773475911662008713141521475920349239466
1201472323512417663521086916214759203492394658
130157734759141862008713140172147592034923946592



Brief information

Clicking on the graph will take you to the comparison page of different models with advanced graph display settings.



Other summary reports for Sivga Audio SV021 Robin Default - REW Loop headphone

report for a newbie

Your browser does not support CanvasA simple report for beginners with explanations of the main characteristics.

Compatibility with amplifier sources

Your browser does not support CanvasA report evaluating the compatibility of Sivga Audio SV021 Robin Default - REW Loop with various amplifier sources.

Target curves and equalization

Your browser does not support CanvasA report with an assessment of compliance with target curves and recommended settings for Sivga Audio SV021 Robin Default - REW Loop equalization



More detailed

Measurements of Sivga Audio SV021 Robin Default - REW Loop were carried out by Roman Kuznetsov on the hardware-software complex RAA.

The Sivga Audio SV021 Robin Default - REW Loop test was conducted as a black box test, without regard to cost and prestige. This is the basic principle for making measurements, measurement reports and developing tests in RAA.

I believe that it is important to do not make an absolute assessment of the device, but an aggregate assessment when working together with a source amplifier and taking into account external factors. This allows you to effectively reveal the potential of the entire set of devices or to make a more optimal choice of components.




Kuznetsov Roman
Founder of RAA



Known by the nickname romanrex
Аuthor of articles iXBT.com



Information for Authors. You can freely use the graphics in your articles with a link to us.




Sivga Audio SV021 Robin is available in reports and services. You are in a professional report.
