Beyerdynamic T1 - Compatibility with amplifier sources

After testing in the benchmark mode in the Reference Audio Analyzer software, the data is added to the online database of the RAA website.

You can view the test results on the comparison pages and summary reports for beginners and professionals. You can go to the desired report or comparison/selection service through the menu on this page. Additionally, you can go to the comparison pages from any graph in this report and add other tested products for direct comparison.

This is the Beyerdynamic T1 compatibility report with amplifier sources.

You can additionally look for Beyerdynamic T1

Variation in frequency response with amplifiers with constant output resistance

Graphics setting view

Channel

Range

Frequency response

Variation in frequency response with amplifiers with constant output resistance @ 20 Hz - 15 kHz

Channel:	Left	Right
Beyerdynamic T1 + TEST 0 ?	0.0	0.0	dB
Beyerdynamic T1 + TEST 10 ?	0.1	0.1	dB
Beyerdynamic T1 + TEST 20 ?	0.1	0.1	dB
Beyerdynamic T1 + TEST 50 ?	0.3	0.3	dB
Beyerdynamic T1 + TEST 100 ?	0.6	0.6	dB
Beyerdynamic T1 + TEST 300 ?	1.5	1.5	dB

Brief information

The test shows a change in the frequency response of headphones when connected to amplifiers whose output impedance is constant in the operating frequency range. The change in frequency response depends on the impedances of the headphones and the amplifier.

Variants of amplifiers with resistances are selected for analysis: 10, 20, 50, 100 and 300 ohms. In the comparison service, you can select any measured amplifiers or use the function tools to set your amplifier by parameters.

The impedance of the amplifier can be of different sizes and, when matched with the impedance of the headphones, the frequency response changes to varying degrees. The lower the output impedance of the amplifier and the higher the impedance of the headphones, the smaller the changes. If the impedance of the amplifier and headphones is flat lines, then there are no changes in the frequency response.

The change in frequency response is gustatory in nature, as an additional equalization or timbre adjustment, leveling or coloring the final sound of the headphones. If desired, the effect of the amplifier can be partially corrected through equalization through the export functions to RAA on the comparison page.

On the frequency response comparison page, there is an export option and additional tools for adjusting the frequency response

Variation in frequency response with amplifiers with constant output resistance

Graphics setting view

Channel

Range

Frequency response

Variation in frequency response with amplifiers with constant output resistance @ 40 Hz

Channel:	Left	Right
Beyerdynamic T1 + TEST 0 ?	0.0	0.0	dB
Beyerdynamic T1 + TEST ? 0 ?	-0.1	-0.1	dB

Brief information

The test shows the deviation of the frequency response of the headphones when connected to amplifiers, the output impedance of which is close to zero in the middle and high frequencies, but increases in the low frequencies. The change in frequency response depends on the impedances of the headphones and the amplifier.

An average version of this type of amplifier was selected for analysis. In the comparison service, you can select any measured amplifiers and look at the individual result.

The higher the headphone resistance, the smaller the changes. The change in frequency response is gustatory in nature, as an additional equalization or timbre adjustment, leveling or coloring the final sound of the headphones.

The change in frequency response is gustatory in nature, as an additional equalization or timbre adjustment, leveling or coloring the final sound of the headphones. If desired, the effect of the amplifier can be partially corrected through equalization through the export functions to RAA on the comparison page.

On the frequency response comparison page, there is an export option and additional tools for adjusting the frequency response

Sensitivity and compatibility with amplifiers

Low-power sources

Graphics setting view

Type of chart

Sound pressure for the environment

Mid-power sources

Graphics setting view

Type of chart

Sound pressure for the environment

Hi-power sources

Graphics setting view

Type of chart

Sound pressure for the environment

Brief information

Clicking on the graph will take you to the comparison page of different models with advanced graph display settings.

Other summary reports for Beyerdynamic T1 headphone

report for a newbie

A simple report for beginners with explanations of the main characteristics.

The main professional report

Main Features and Graphics for Beyerdynamic T1

Target curves and equalization

A report with an assessment of compliance with target curves and recommended settings for Beyerdynamic T1 equalization

More detailed

Measurements of Beyerdynamic T1 were carried out by Roman Kuznetsov on the hardware-software complex RAA.

The Beyerdynamic T1 test was conducted as a black box test, without regard to cost and prestige. This is the basic principle for making measurements, measurement reports and developing tests in RAA.

I believe that it is important to do not make an absolute assessment of the device, but an aggregate assessment when working together with a source amplifier and taking into account external factors. This allows you to effectively reveal the potential of the entire set of devices or to make a more optimal choice of components.

Kuznetsov Roman
Founder of RAA

Known by the nickname romanrex
Аuthor of articles iXBT.com

Information for Authors. You can freely use the graphics in your articles with a link to us.
